Wireless
| Standards | IEEE 802.11a/b/g/n/ac/ax |
| Signal Rate | 2.4GHz Up to 574Mbps 5 GHz UP to 2400Mbps |
| Frequency Range | 2.412-2.472GHz :574Mbps 5.180-5.825GHz :2400Mbps |
| Wireless Mode | Station |
| Bluetooth | Blutooth 5.0 |
Hardware
| Port | PCIE-X1 |
| Button | N/A |
| Dimensions | Size: 72*46mm; Antenna Size:143mm |
Others
| Certification | FCC, CE, KC |
| System Requirements | Windows10 / Linux / Chrome |
| Environment | Working Temperature: 0 C~40 C Storage Temperature: -40 C~70 C Working Humidity: 10%~90%RH Non-condensing Storage Humidity: 5%~90%RH Non-condensing |
| Package | 1 * F1 1 * Driver CD 2* External antennas 1 * Quick Installation Guide |
