MW5300
Thiết bị phát Wifi sử dụng SIM 4G LTE
- Băng tần 2.4GHz
- Ăng-ten 2x5dBi LTE, 2x5dBi WiFi
- Chế độ không dây: 4G Router/AP/Router
- 2 port x 10/100Mbps LAN, 1 port x 10/100Mbps WAN
- Truy cập tối đa: 30-35 user
Hỗ trợ tư vấn:
Hotline: 0868 527 555
Hotline: 0868 527 555
Hardware
| Interface | 1 x 10/100Mbps WAN port
2 x 10/100Mbps LAN ports |
| LED | PWR，WAN，LAN，2.4G，4G, WPS |
| Button | Reset，WPS |
| Power Supply | DC 12V/1A |
| Antennas/Antenna Gain | 2.4G : 2T2R , 4G : 2T2R
5dBi |
Software
| Frequency | 802.11b/g/n : 2.4~2.4835GHz |
| Radio Rate | 2.4G : Up to 300Mbps |
| WPS | Support |
| Modulation | 11b : CCK, QPSK, BPSK
11g : OFDM 11n : QPSK，BPSK，16-QAM，64-QAM |
| Receiver Sensitivity | 2.4G: 11b : <-84dbm@11Mbps;
11g : <-69dbm@ 54Mbps; 11n: HT20<-67dbm HT40: <-64dbm |
| 4G Module | LTE CAT4 |
| GSM | 900MHz/1800MHz |
| GNSS | GPS, GLONASS, BeiDou/Compass, Galileo, QZSS |
| Mode | 4G Router/AP/Router |
| WiFi Setting | Wireless Setting、Channel bandwidth Setting、WPS |
| Status | CPU Status、Interface Status、4G Status
Client List Internet Status |
| Network | LAN, WAN, DHCP, APN |
| Traffic assistant | Username Management
Reboot Upgrade/Restore/Bankup Sys time & date Sys logs |
| Setting Guide | Type of connect Internet
Network WiFi |
Others
| Dimensions | 185 *145*32mm |
| Environment | Operating Temperature : Normal:0°C to +45°C
Operating Humidity：-20° C to +70° C Operating Humidity：5%~ 95% Storage Humidity：5%~ 95% |
