Hardware
Interface | 1*10//100/100/1000M AUTO MDI/MDIX RJ45 LAN ports
1*10/100/100/1000M AUTO MDI/MDIX RJ45 WAN ports 3*10/100/100/1000M AUTO MDI/MDIX RJ45 WAN/LAN ports |
LED | PWR, Ports, SYS |
Button | Reset Button |
Forwarding rate | 10/100/1000Mbps |
CPU | Dual core(880MHz*2) |
FLASH | 16MB |
Memory | 128MB |
Power Supply | Built-in 12V/1.5A |
Software
Applications | Policy routing
Dynamic domain name Remote access Port mapping Static routing |
Standard | IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3x, IEEE802.1x |
Network | External network Settings
Intranet Settings DHCP DNS Dynamic domain name Static routing Hostname Interface Settings Port mapping uPnP Settings Switch |
AC management | AC Control
AP Setup Control AP Template setup AP RF settings AP Advanced settings AP Device management AP Setup upgrade |
Remote management | BeeWiFi |
Setup wizard | Quick Configuration Wizard
Expert Wizard |
System | Overview
State System log Host monitoring Real-time monitoring Historical monitoring Application statistics Interface Overview |
Group management | IP group
Time group Port group Application group MAC group Domain name group |
Behavior management | One-click control
Firewall rules URL redirection URL filtering DNS filtering WEB access log |
Virtual private network | PPTP Server
PPTP client L2TP server L2TP client IPSEC |
Advanced features | Secondary protection routing
Shared decryption PPPoE relay Port image Network wake-up |
System management | System Settings
Toolbox Persistent ping Join the cloud Scheduled tasks Route cipher Firmware upgrade Feature library upgrade Restore the default Backup/Restore |
Others
Dimensions | 280*173*44mm |
Environment | Operating Temperature : 0℃ ~ 40℃
Operating Humidity : 10% ~ 90% RH non condensing Storage Temperature : -20℃ ~ 70℃ Storage Humidity : 5% ~ 95% RH non condensing |
