Hardware
Interface | 4*10/100Mbps POE Ports(Data/Power)
2*10/100Mbps RJ45 Ports(Data) |
Backplane Bandwidth | 1.2G |
MAC Address Table Size | 2K |
Power Supply | AC input 100-240V, standard 52W power supply |
Cabling Type | 100Base-TX: 2 pairs of class 5 (Cat5) or more UTP/STP(≤100m)
10Base-TX: 2 pairs of class 5 (Cat6) or above UTP/STP(≤250m) |
Software
Basic Functions | Follow IEEE 802.3 Ethernet IEEE802.3u Fast Ethernet Protocol standards
Support POE IEEE 802. 3af/at compliant Powered Device (PD) Store-and-forward switching scheme Compatible with certified non-standard electrified equipment (PD) Support IEEE802.3X full duplex and Backpressure half duplex flow control MAC address auto-learning & auto-aging |
Standards | IEEE 802.3 10BASE-T Ethernet
IEEE 802.3i 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3af/at, Power over Ethernet IEEE 802.3x Flow Control |
Transfer Rate | Ethernet 10Mbps half duplex, 20Mbps full duplex
Fast Ethernet 100Mbps half duplex, 200Mbps full duplex Gigabit Ethernet 2000Mbs full duplex |
Cloud Managed Information | Switch SN information, device model, firmware version, real-time IP, real-time port power, port LINK status, link duplex, uplink and downlink rates |
Other
Temperature | Operating temperature:0℃~40℃
Storage temperature:-20℃~70℃ |
Humidity | Operating humidity:10%~90% RH Non-condensing
Storage humidity:5%~90% RH Non-condensing |
Dimensional | 125mm*115mm*34mm (L*W*H) |
